Product Overview
GL-1200- Manual
Overview
GateSet Eco Line GL-1200 Series Manual Leaf Swing Gate Turnstiles are an economical alternative to regulate pedestrian traffic. Thanks to its compact design, GL-1200 Series Leaf Swing Gates are an ideal solution to provide controlled passage for pedestrians and carrying goods. GL-1200 Series provides passage in one direction, and is available with manual lock with key or electromagnetic lock with access control. GL-1200 Series Swing Gates are applicable in shopping malls, supermarkets, fitness/wellness centers including tight areas with its compact, aesthetic and user friendly design.
Technical Specifications
MATERIAL - MAIN BODY
:
304 grade stainless steel, polished finishing
MATERIAL - SWING ARM
:
Steel profile frame with 32 mm diameter
TREATMENT - OTHER PARTS
:
All other parts are coated against corrosion
DIMENSIONS (mm)
:
918 x 164 x 1080 (WxLxH)
SWING ARM LENGTH (mm)
:
800
OPERATING VOLTAGE
:
GL-1000 / GL-1100: None GL-1200: 115-240 V AC / 24 V DC - 50-60 Hz
OPERATING TEMPERATURE
:
-20 0C / + 70 0C
ACCESS CONTROL
:
GL-1000: None, free passage only in one direction GL-1100: Physical lock with manual key GL-1200: Granting access with 180 KG holding force electromagnetic lock.
OPERATIONAL MODE
:
Easy integration with all kind of access control equipment
AUTO CLOSE
:
Arm will return to center position automatically
OPERATION SAFETY
:
Electrical and mechanical safety for all component. To avoid injuries, all corners and sides are rounded
ELECTRICAL FAILURES
:
In an emergency case, main mechanism released and unlocked automatically. Turnstile would be free to open to manually in order to ensure fast evacuation. (Applied for GL-1200 only)
CERTIFICATION
:
ISO 9001:2008
WARRANTY
:
2 Years
